Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive

Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive

Electric AGV Automated Guided Vehicle

1500KG Load AGV Automated Guided Vehicle

Place of Origin:

GUANGZHOU

Brand Name:

TIANYUE

Certification:

3c.ce

Model Number:

TY-FB-SD-1500kg

Document:

Product Brochure PDF

Contact Us
Request A Quote
Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive
Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive Electric Single-Lift Omnidirectional AGV Automated Guided Vehicle 1500KG Load Capacity Steering Wheel Drive
Product Details
Motor Way:
Servo Motor
Drive Mode:
Dual Steering Wheel Drive
Docking Mod:
Lifting Platform
Size:
Customization
Power Supply:
Lithium Iron Phosphate
Appearance:
Customization
Load Weight:
1000KG-1500KG
Highlight:

Electric AGV Automated Guided Vehicle

,

1500KG Load AGV Automated Guided Vehicle

Payment & Shipping Terms
Minimum Order Quantity
1
Packaging Details
wooden box
Delivery Time
50 work days
Payment Terms
T/T
Supply Ability
100
RELATED PRODUCTS
Good price Light Load Conveyor Chassis AGV Automated Guided Carts Carrying 100KG Differential Drive online Video

Light Load Conveyor Chassis AGV Automated Guided Carts Carrying 100KG Differential Drive

Get Best Price
Good price Customized Front Fork AGV Automated Guided Vehicle Capacity 100KG Customized Size online Video

Customized Front Fork AGV Automated Guided Vehicle Capacity 100KG Customized Size

Get Best Price
Good price 300KG AGV Vehicle Double Layer Transmission Of Photovoltaic Materials In Narrow Channels online Video

300KG AGV Vehicle Double Layer Transmission Of Photovoltaic Materials In Narrow Channels

Get Best Price
Good price Dive Traction AGV Automated Guided Vehicle Traction Weight 1000KG Differential Drive online Video

Dive Traction AGV Automated Guided Vehicle Traction Weight 1000KG Differential Drive

Get Best Price
Contact Us
13570415240
mkliangjintian@gmail.com
Contact Now
Product Description

AGV Automated Guided Vehicle Electric single-lift omnidirectional AGV, 1500KG load capacity, steering wheel drive, custom



Lifting Assembly Platform AGV Technical Specifications

Item Technical Parameters
Product Name Lifting Assembly Platform AGV
Product Dimensions L x W x H mm (customizable)
Loading Mode Electric rigid chain structure platform lifting, lifting stroke customizable 1M, powered roller docking method
Load Capacity 1000KG-1500KG (customizable)
Control Mode PLC, Microcontroller (customizable)
Navigation Mode Laser, QR code, Magnetic tape (customizable)
Travel Direction Forward, backward, left turn, right turn, bifurcation, 360° rotation, lateral, transverse, omnidirectional
Drive Mode Steering wheel drive
Drive Steering Power 1000W * 2, 400W * 2
Drive Power Supply DC 48V
Travel Speed Straight: 0-40 m/min, Turning: 0-20 m/min
Repeat Positioning Accuracy ±5mm
Allowed Surface Flatness ≤5 mm
Working Mode Can work continuously for 24 hours
Climbing Ability ≤5%
Charging Mode Online charging (side charging)
Obstacle Sensor Safety Sensing Range Detection distance: ≤3 m (adjustable), Sensor detection angle: ≤270° (adjustable), Emergency braking distance: < 20 mm
Safety Protection Front obstacle detection sensor, dual protection safety edge anti-collision mechanism, emergency stop switch
Alarm Mode Audible and visual alarm, tri-color light, musical horn
Working Noise Below 70 dB (A)
Battery Type: Lithium iron phosphate battery, Voltage: 48V, Capacity: 150Ah (customizable)
Design Life >10 years
